Sheet Metal Feeders

Sheet Metal Feeders

Sheet Metal Feeders
CategoriesPress Feed Equipments
AlbumView larger image
BrandHONGER
ModelRNC-B
Servo MotorJapan Yaskawa
PLCJapan Mitsubishi
CE CertificatePassed
Air CylinderJapan CKD
Man-machine interfaceMitsubishi of Japan
BearingJapan NSK
Suitable Coil Width0-1000mm
Suitable Coil Thickness0.5-4.5mm
Multistage Feeding FunctionWith
Save Data To MemoryWith
FOB portShenzhen Port or China other port
Terms of PaymentL/C, D/A, D/P, T/T, Western Union, MoneyGram
Update Time2018-11-18
Detail Information

About Sheet Metal Feeders:


1.Sheet Metal Feeders Introduction:


1. Our Sheet Metal Feeders speed can reach 0-20 m/min.  Precision is better than +/-0.05 mm. And suitable all kinds of  metal coil.


2. Our Sheet Metal Feeders is suitable 0.5-4.5 mm thickness all metal coil feeding.


3. Our Sheet Metal Feeders widely used to computer, mobile phone,automobile industry,appliances manufacturing, medical

   apparatus and instruments, hardware & Metal parts etc industry.

2 .Sheet Metal Feeders Feature And Advantage:

1. High precision:+/-0.05 mm


2. Suitable for material thickness :0.5-4.5 mm.


3.Suitable for all kinds of metal coil automatic feeding,easy to operate.


4.Suitable for metal parts, electron, electrical appliance, toy and auto parts continuous pressing production, straightening and      feeding.


5. Japan servo motor , PLC and other electrical parts,with little malfunction and long using time.High quality ,lowest maintenance.


6. Can feed different length at the time,easy operation, safe and high stability.


7. We can customize the machine.


8.Fast speed: 20 m/min. If you need more high speed ,we can reach 40 m/min.


9.Oiling machine etc. for choosing.


3.Sheet Metal Feeders Main Parts Brand:


Motor


YASKAWA

PLC


Mitsubishi

Man-machine interface


Weinview

Driver


YASKAWA

CE Certificate


Passed

Feeding way


Automatic

Feeding control way


Servo motor with PLC

Bearing


Japan NSK

Air cylinder


Japan CKD

Big customer


Media, Haier , AUDI, DONGFENG etc.



3.Sheet Metal Feeders Technology Data:


Name


Sheet Metal Feeders

Model


RNC-300B

RNC-400B

RNC-500B

RNC-600B

RNC-700B

RNC-800B

RNC-900B

RNC-1000B

Max. Coil width


300mm

400mm

500mm

600mm

700mm

800mm

900mm

1000mm

Feeding length


0-9999.99 mm

Coil thickness


0.5-4.5 mm

Bottom mould height

150-320 mm

Feeding speed


0-20 m/min

Feeding capacity     (W x T)   (mm)

300 x 3.0

400x 3.0

500 x 3.0

600 x 3.0

700 x 3.0

800 x 3.0

900 x 3.0

1000 x 3.0

80mm x 4.5mm

Release way


Pneumatic

Servo motor


YASKAWA from Japan

PLC


Mitsubishi from Japan

Man-machine interface

WEINVIEW from Taiwan

Control way


Electric control cabinet and hand switch box

Drive way


Double geared

Feeding roller


1 group roller (2 pcs)

2 groups roller (4 pcs)


4.Our Sheet Metal Feeders In Our Our Factory,Have Exported To Algeria:




5.Sheet Metal Feeders Producing Line:





About Hong-Er Machine:
1.  Hong-Er Machine Introduction
Shenzhen Honger Machine Equipment Co.,Ltd are professional Sheet Metal Feeders,2 In 1 Sheet Steel
Straightener And Uncoiler, Decoiler Straightener Feeder,Sheet Metal Press Machine,Punching Press Machine,Decoiling
and Straightening Machine,NC Servo Roll Feeder,Servo Roll Feeder,Zig Zag Feeder,Mechanical Feeder,
Rapid Air Feeder,Uncoiler Machine,Sheet Metal Decoiler,Strip Straightening Machine,Sheet
Straightening Machine Manufacturer/Factory/Supplier/Exporter in Guangdong of China.
We are the only own international advanced big CNC that include FPW & VMC.
The Top one quality best price Machine manufacturer in Guangdong.
We are near to Hongkong,Guanggou,Dongguan etc. And Shenzhen Baoan Airport is
international airport,If you want to visit us ,that is very convenient.
Welcome to visit our factory!
2.Hong-Er Machine CE Certificate:



3.Hong-Er Factory And Workshop:




About Hong-Er Service:


1. We Can Provide To Buyer Details Requirement:


Package

Wooden case and film package

After-Sale service

1 Year

Delivery time

0-20 workdays

Shipping way

Ocean shipping

Payment term

T/T  L/C  Cash or other



2.Sheet Metal Feeders Packing:wooden case or other package. According to the actual condition.
